Linear Typing Feel
The Oil King switch is the newest mechanical linear switch that features a Nylon PA66 upper housing, a housing base made of secret black Ink housing material, and a POM stem. The stem in the upper housing is fantastic with ultra-stability and almost no wobbliness. Compared to CJs, it has a deeper patch sound.
![Gateron Oil King Switch Gateron Oil King Switch](https://cdn.shopify.com/s/files/1/0568/8514/9779/t/3/assets/gateron-oil-king-switch2-1654856217881-1663298942572_1200x.jpg?v=1663298943)
Gold Contact
The gold contact improves anti-oxidation performance and protects the key switch from corrosion, guaranteeing the switch will last for up to 60 million cycles.
Pre-Lubed
The Oil King switch is pre-lubed to help avoid spring ping and unnecessary friction and hitches.
![Gateron Oil King Switch Gateron Oil King Switch](https://cdn.shopify.com/s/files/1/0568/8514/9779/t/3/assets/gateron-oil-king-switch-1654856054908-1663299379602_1200x.jpg?v=1663299380)
![Black Plated Spring Black Plated Spring](https://cdn.shopify.com/s/files/1/0568/8514/9779/t/3/assets/gateron-oil-king-switch4-1654918208553-1663299430369_1200x.jpg?v=1663299431)
Black Plated Spring
The Oil King switch incorporates a long 20 mm black plated spring allowing for 55 gf actuation and 80 gf bottom-out weight, creating a rather unique and super-smooth typing feeling.
Features
Type | Linear |
---|---|
Operation Force | 55±5 gf |
Pre-Travel | 2.0±0.6 mm |
Total Travel | 4.0 mm Max |
Spring | 20 mm |
Sound Level | Low |
Operation Life | Up to 60 m cycles |
Suitable For | Gaming / Office |
Typing Feel | Vertical, strong, actuation force, hard rebound |
![Gateron Oil King Switch Force Travel Diagram Gateron Oil King Switch Force Travel Diagram](https://cdn.shopify.com/s/files/1/0568/8514/9779/t/3/assets/gateron-ink-red-switch-force-travel-graph-1-1653984055744-1663299816469_1200x.jpg?v=1663299816)
Specs
Product Name | Gateron Oil King Linear Switch |
---|---|
Stem | POM, MX stem |
Upper Housing | Nylon PA66 |
Housing Base | Proprietary "INK" blend |
Spring | Spring steel |
Pins | 5-Pin switch |
Lubrication | Yes |
SMD LED Support | Yes (only support unraised SMD-LED) |
Compatible Keyboards
Any Gateron G Pro Mechanical (Hot-Swappable) version, Keychron Mechanical (Hot-Swappable) version, Q series or V series Keychron keyboards.
![Gateron Oil King Switch Layout of PCB Gateron Oil King Switch Layout of PCB](https://cdn.shopify.com/s/files/1/0568/8514/9779/t/3/assets/gateron-kangroo-ink-box-switch-layout-of-pcb-1654761711364-1663299999366_1200x.png?v=1663300000)
Notice: Due to the housing design of the Gateron Oil King switches, the backlight effect will not be that visible.
