Gateron Oil King-schakelaar
Linear Typing Feel
The Oil King switch is the newest mechanical linear switch that features a Nylon PA66 upper housing, a housing base made of secret black Ink housing material, and a POM stem. The stem in the upper housing is fantastic with ultra-stability and almost no wobbliness. Compared to CJs, it has a deeper patch sound.
Gold Contact
The gold contact improves anti-oxidation performance and protects the key switch from corrosion, guaranteeing the switch will last for up to 60 million cycles.
Pre-Lubed
The Oil King switch is pre-lubed to help avoid spring ping and unnecessary friction and hitches.
Black Plated Spring
The Oil King switch incorporates a long 20 mm black plated spring allowing for 55 gf actuation and 80 gf bottom-out weight, creating a rather unique and super-smooth typing feeling.
Features
| Type | Linear |
|---|---|
| Operation Force | 55±5 gf |
| Pre-Travel | 2.0±0.6 mm |
| Total Travel | 4.0 mm Max |
| Spring | 20 mm |
| Sound Level | Low |
| Operation Life | Up to 60 m cycles |
| Suitable For | Gaming / Office |
| Typing Feel | Vertical, strong, actuation force, hard rebound |
Specs
| Product Name | Gateron Oil King Linear Switch |
|---|---|
| Stem | POM, MX stem |
| Upper Housing | Nylon PA66 |
| Housing Base | Proprietary "INK" blend |
| Spring | Spring steel |
| Pins | 5-Pin switch |
| Lubrication | Yes |
| SMD LED Support | Yes (only support unraised SMD-LED) |
Compatible Keyboards
Any K series (Gateron Mechanical Hot-Swappable or Keychron Mechanical Hot-Swappable versions only), K Pro series (Normal-profile versions only), C and C Pro series (Hot-Swappable versions only), V and V Max series, Q, Q Pro and Q Max series Keychron keyboards, and L and P Series Lemokey keyboards.
Notice: Due to the housing design of the Gateron Oil King switches, the backlight effect will not be that visible.
